HSeries

AUTOMATIC PATTERN POLISHING MACHINE

Irregular pattern polishing for workpiece surface. Improve adhesion and extend duration of rust prevention
  • Applicable MaterialCarbon Steel,Stainless Steel,Copper,Aluminum,etc.
  • Station CombinationTwo or more H stations,can combined with other station or perform tow-side pattern polishing
  • Conveying And FixingPerforated belt conveying ,vacuum adsorption fixation
  • Processing ResultUniform surface with irregular pattern
Features
  • Irregular pattern surface after processing
  • Increase surface roughness
  • Restore slight scratch on surface
  • Fingerprint mark prevention
  • Working together with other stations can realize deburring,edge rounding and polishing effect
  • Memory of process parameters
Technical Parameters
Working Width 800mm/1000mm/1300mm
Working Thickness 0.8-60mm
Conveyor Speed 0.8-4m/min(frequency control)
MAX.POWER 30KW/30KW/35KW(including high pressure blower)
Rated Voltage AC 380V/50Hz
Compressed Air 0.6-0.8Mpa
Weight 3800kg/4500kg/5500kg
Sample Parts Photo
